Product advantage
Safety: High-quality 2.5mm thick 304 stainless steel shell is selected, which is corrosion-resistant and colorfast, and can effectively resist impact and external force damage.
Customization: the guard height, the number of light beams and the surface spraying process can be flexibly customized according to the customer's requirements.
Independent identification of beams: each beam adopts different frequencies to independently identify and receive laser signals, so as to avoid false reports and false alarms caused by external environment interference and laser beam crosstalk.
The first front dimming: the front dimming design solves the technical problem of inconvenient debugging caused by dead angle in installation.
On-site sound and light alarm: High decibel sound and light warning lamp can be selected to realize on-site sound and light alarm.
Super-large lens, super-concentrated light: the light receiving area is 4 times larger than that of the traditional products; the φ Φ60mm high-transmittance condensing lens is adopted for receiving, which greatly improves the condensing capacity.
Anti-glare interference: The receiver adopts professional narrow-band filter+band-pass filter technology, which can effectively filter out 99% stray light from the outside, and is not interfered by light sources such as sunlight, searchlights and automobile glare.
Multi-gear response adjustment: the alarm response time can be adjusted in multiple gears, which is suitable for various application environments and meets various alarm requirements;
Durability: The semiconductor laser imported from Germany, pulse coding of light source, constant power control, has a service life of up to 10 years.
Basic parameter
Laser Detector
Number of defense zones: 1
Product dimensions: 100mm (length) ×100mm (width) ×1800mm (height)
Communication mode: network communication, RS485 communication, switch communication.
Laser wavelength: 650nm, 808nm, 980nm (optional)
Alarm time: 2s 1s (1-30s optional)
Response time: 5ms-500ms (five-gear adjustable)
Laser light source type: a kind of safe laser light source,
Grade: class I
MTBF ＞120000 hours
And power supply environment parameters
Power supply voltage: DC10 ~ 30V/2A
Environment: temperature-40 ~+70℃; Humidity ≤95%
humanization design
Material: high-strength metal.
Protection level: IP67
Installation requirements
Length of defense zone: 50m, 100m, 200m, 300m, 400m, 500m
Alert level: 8 alert levels (other heights can be customized)
system composition
